© Johnstone Supply eCatalog 222

Residential Commercial Refrigeration Facilities The Right Solutions For All Your Needs 2026 Catalog, 222 Over 35,000 Products

©2022 Johnstone Supply © 2026 JOHNSTONE SUPPLY, LLC. All rights reserved. No part of this catalog may be reproduced in any form without written permission from JOHNSTONE SUPPLY, LLC. Coleman® HVAC residential heat pumps HH8 Side-Discharge Heat Pump 18+ SEER2 Variable speed Premium performance and efficiency in a small footprint Now you can get the performance and efficiency you’ve always wanted from one compact, side-discharge solution. This unit offers variable-speed operation and climate control for homeowners, as well as an easy-to-install solution for contractors. The choice is simple. Benefits • Side-discharge design and compact footprint for ducted systems • Premium solution for hybrid system applications when paired with a gas furnace • Optimized matches to meet eligibility requirements for most federal and regional tax credits, rebates and other incentives* • Premium, variable-capacity performance provides more consistent comfort • Inverter-driven, variable speed provides consistent comfort • Can be paired with existing non-Coleman® HVAC gas furnaces * Contact your local Johnstone Supply for specific details.

MAKING IT EASY FOR THE CONTRACTOR For decades, Johnstone Supply has been your one-stop shop for leading brands of HVACR equipment, parts and supplies. But these days, your business success depends on more than a great range of products. Today’s contractors need to stay current on product and technology changes, in addition to programs that make it easier to do business. We deliver solutions: • A website and mobile app that offer our customers real-time pricing and availability • A state-of the-art model-to-part, and part-to-part cross-reference utility that can locate virtually any HVACR product regardless of the brand or age • Equipment Selector Tools: System Selector and Mini Split Selector allow you to easily identify and order AHRI Certified HVAC Systems that meet rating requirements and the application needs and identify rebates • In‑person & online training to educate you on products, trends, changes, and certifications • Access to 2 million special order parts MOTORS & MOTOR ACCESSORIES VENTILATION & INDOOR AIR QUALITY AC HEATING & CONTROLS HYDRONICS HVAC EQUIPMENT INSTALLATION & MAINTENANCE REFRIGERATION & AIR CONDITIONING TEST INSTRUMENTS & TOOLS

V YOUR ONE STOP FOR ALL YOUR OEM REPLACEMENT PARTS Johnstone excels at stocking industry-leading repair, replacement parts and equipment so that you have the right product right when you need it for residential, commercial, refrigeration or facilities maintenance. The JohnstoneSupply.com online catalog contains 70,000 stocked products, and most locations across the country offer a unique local selection. With six distribution centers in our supply chain network, you can be sure our 450+ stores either have your product available in stock same day or can receive it overnight. Our manufacturer partners offer us the availability of their entire line — whether we stock it or not — for those times when your need is critical. That amounts to over a million special order parts available to you. We stock hundreds of OEM parts for nearly every major brand so you don’t have to wait. Plus, using our proprietary cross-reference utility, we can find hard-to-locate and even obsolete parts and recommend quality replacements for repairs on older or more obscure equipment.

VI • Get Techs Job Ready with our Tech Fundamentals Flex Program • Maintain NATE Certi cation • Keep your technical skills current • Stay safe, productive, and compliant • Increase revenue • Track progress and earn rewards • Train on your time Online you will learn how to: IT'S FREE TO REGISTER, SIGN UP, AND START LEARNING TODAY! JohnstoneUniversity.com LEARNING THAT EARNS Grow your skills, profits, and FREE time by adding to your “toolbox” with training!

A FEW MORE THINGS ABOUT HOW WE DO BUSINESS. Identification may be required of purchasers. Possession of Johnstone’s catalog does not constitute an offer to sell by Johnstone, or the right to purchase from us. Subject to change without notice. Quantity prices are available on selected items and will be quoted on request. It is Johnstone’s policy to ship all orders the same day as received if possible. All Johnstone outlets are stocking warehouses with inventories for immediate delivery where available. Open account terms are available to firms with established credit. If credit is not established please authorize C.O.D. shipment or send check with order. Past due accounts may be subject to a service charge. Johnstone Supply will administer and promptly process all warranties in accordance with the manufacturer’s specified warranty policies and procedures. Contact your local Johnstone Supply for their freight policy. Contact your local Johnstone Supply for their return policy. All returns must have prior approval and are subject to a restocking charge. Johnstone is committed to illustrate and describe all the products in this catalog accurately. Such descriptions and illustrations are for the sole purpose of identification, and do not imply that the products will fit for a particular purpose, or that they will conform to the descriptions or illustrations. No guarantee or warranty other than set forth above is made or authorized by Johnstone. Johnstone’s liability in all events is limited to the purchase price paid. Due to conditions beyond our control we are unable to guarantee the prices in this catalog for any length of time. Prices in this catalog are only suggested and may vary from time to time because of conditions or by location. WHOLESALE ONLY PRICES SERVICE CREDIT TERMS WARRANTY FREIGHT RETURNS WARRANTY DISCLAIMER PRICES SUBJECT TO CHANGE WITHOUT NOTICE HVACanswers.com Johnstone Supply is invested in your success—join Find a Pro today. Are you looking for new customers? Then get listed as a trusted professional. 1. Go to HVACanswers.com and click on Find a Pro 2. Click on Not listed? Start here 3. Enter your business details 4. Click Save

TRAINING • INVENTORY • SUPPORT Whether you visit a location or shop online, we handle your purchase with speed and respect for your needs. Our friendly experts are here to help you locate replacement parts or special order products. We are your Supportive Business Ally • We leverage technology and content to help your needs • We have a network of distribution facilities that provide rapid order ful llment of a wide variety of products We know that your success comes when you can get back on the road quickly. You can count on Johnstone to be your rst and best supplier, and to offer a wide array of solutions. Because service isn’t just being fast at the counter, it’s offering what you need before you even need it. We are your partner in success — here to make it easy for you to do business.

www.JohnstoneSupply.com 2026 Product Showcase FPO 2026 Product Showcase Bosch Ad Space PRODUCT SHOWCASE 2025 RESIDENTIAL COMMERCIAL REFRIGERATION FACILITIES EQUIPMENT SUPPLIES PARTS Delivering exceptional home comfort through quality engineering, TXLHW SHUIRUPDQFH DQG SUHPLXP HΙFLHQF\ As the market grows, so do we. Bosch’s full line of products now available at your local Johnstone Supply

©2022 Johnstone Supply Voltex® Max Smart Hybrid Electric Heat Pump Water Heater with Hot Water+ Technology Adapt™+ Premium Condensing Gas Tankless Water Heater with X3® Scale Prevention Technology HIGH EFFICIENCY INNOVATIONS Versatile Fit – Top connections, zero clearance required, and built-in ducting adaptors for tight spaces Efficient Performance – Hot Water+ boosts delivery, Guest Mode handles peak demand, and Whisper Quiet 45dBA operation Advanced Protection – iCOMM™ Smart App, leak detection with auto shutoff, and a smart anode for longer tank life Unmatched Durability – X3® Scale Prevention triples lifespan with no hard water warranty exclusions.* Adaptable Installation – Supports 2” or 3” PVC venting, includes NG-to-LP conversion kit, and works indoors or outdoors.** Superior Performance – Stainless steel heat exchanger, built-in recirculation pump, and sustained “like-new” efficiency. Order # Mfg. # Gallons Diameter Volts N99-394 HPTA-40 40 20” 208-240 N99-395 HPTA-50 50 22” 208-240 N99-396 HPTA-66 66 26-1/2” 208-240 N99-397 HPTA-80 80 26-1/2” 208-240 Order # Mfg. # Fuel Type Min BTU Max BTU N99-378 ATHR-160X3 NG or LP 9,000 160,000 N99-379 ATHR-180X3 NG or LP 9,000 180,000 N99-380 ATHR-199X3 NG or LP 9,000 199,000 *Compared to tankless models without X3 technology. **Outdoor Vent Cap Kit Required.

www.JohnstoneSupply.com Order # Mfg. # HP Volts S83-698 6203X 1/3 208-230 S83-699 6205X 1/2 208-230 Order # Mfg. # HP Volts S83-694 6503VUI 1/3 120/240 S83-695 6505VUI 1/2 120/240 Order # Mfg. # Description Frame Volts Efficiency S83-669 FX34BK003 3/4HP 3PH 56HC 460 V 81% 5-PIN SOLUTION 4-PIN SOLUTION 16-PIN SOLUTION Designed to replace OEM constant torque ECMs with 24 VAC speed taps An easy plug-in-play replacement for 16-pin and 4-pin variable ECM speed motors Ready to configure into any mounting position User Interface included in box Quick install video online* *must be logged in to view Quick install video online* *must be logged in to view

©2022 Johnstone Supply Industry Leading Performance and Water Savings 620 Large Bypass Evaporative Humidifier with HydroCore™ Technology Superior Performance, Less Wastewater* • Increased capacity at 18 GPD • Ideal for tightly built homes up to 5,300 ft • Reconfigurable bypass (right or left) for flexible supply or return duct installation • Adjustable dampers for high-pressure system compatibility • Catch-all drain minimizes leaks • Serviceable without closing - reduces errors Item# Mfg.#: Description Daily Output B88-286 620A 620A HUMIDIFIER AUTO 18 gallons B88-287 620M 620A HUMIDIFIER MANUAL 18 gallons *Compared to the AprilAire 600 Humidifier • One-piece disposable HydroCore™ water panel cartridge snaps in and out for fast maintenance • HydroCore™ Technology Recirculates water to maximize panel saturation with a 55% reduction in wastewater* • Compatible with both 620 and 720 Series One-Piece HydroCore™ NEW

www.JohnstoneSupply.com NEW • Works with most 24 VAC HVAC Systems • Supports 1-wire accessory control • 4H/2C, Dual Fuel Systems Power Extender Kit L51-923 Mfg. #EB-STATE7P-01 L51-925 Mfg. #EB-PEK2-01 (PEK) sold separately Proudly designed, engineered, and manufactured in the USA IAQ Products You Can Count On Purifies air throughout the air-conditioned space. Bulb change reminder via countdown timer. Helps reduce bacteria, viruses, odors, mold, allergens and dust at the source. L83-035 Mfg. #REME-LED-AS REME HALO LED™ Purifies air throughout the air-conditioned space. Bulb change reminder via countdown timer. Helps reduce bacteria, viruses, odors, and mold. L83-034 Mfg. #REME-H-T REME HALO® Whole Home In-Duct Air Purifiers

©2022 Johnstone Supply Condensate Management Connected Wet Switch® Flood Detector B22-996 Mfg # WS-1C The Asurity® WS-1C Wet Switch® Connected Flood Detector is a smart Wi-Fi enabled switch designed to: • • Turn the system off when detecting moisture due to condensate or drain leaks • Includes a built-in test/reset button. • Immediately send a text or email when water is detected alert about potential moisture problems. FAMILY OF BRANDS Comfortable workspaces start with Modine Hot Dawg® and Amp Dawg™ garage heaters. Amp Dawg™ Electric Unit Heater (AMP) • Available in 5.7kW and 9.0kW for installation flexibility Hot Dawg™ H 2O Low-Profile Hot Water Unit Heater (HHD) • Available in 3 model sizes that run off your boiler system, ground source heat pump, or hot water heater Hot Dawg® Gas-Fired Unit Heaters (HD/HDS) • 30,000 to 125,000 BTU • Operates on natural or propane gas, field conversion kits are available CREATE THE ULTIMATE WORKSPACE OASIS WITH VERSATILE HEATING SOLUTIONS FROM MODINE®

www.JohnstoneSupply.com TheZONELINE Cutting-Edge Inverter Technology Meet GE Appliances’ �rst PTAC to use inverter technology and a variable-speed compressor that gives guests more comfort, more often. The variable speed compressor and advanced defrost capability allow for the best-in-class heat pump operation down to 0°F. E�cient Cold Weather Heat Pump Cost-Saving Performance A variable-speed compressor drastically reduces energy-intense startup cycles, which can help save money on electricity and utility costs. $ Whisper-Quiet Operation A large cross-�ow blower, a variable speed compressor and two EC motors work together to minimize noise and maximize comfort. L50-099 Zone Valve with Press Connection • 1/2" Zone Valve Pro Press • 18" lead wires and End Switch One-Stop Hydronics Shop L51-016 AquaPUMP Variable Speed Stainless Steel Circulator • Wet Rotor Variable Speed ECM 120V • Stainless Steel Circulator L82-543 Boiler Trim Kit with SuperVent • 1" Press (SuperVent) • Supreme Trim Kit with NK300S Boiler Feed Combo Valve Central Air Conditioner/Heat Pump Soft Starter Air conditioner soft starters help homeowners get better performance from central A/C units - and extend the life of A/C units. SoftStartHome™ reduces the power required to start an air conditioner by 50-70%. B22-998 Mfg# SSH6T B22-997 Mfg# SSH3T Application: Systems up to 6 Tons (72,000 BTUs) and 3 Tons (36,000 BTUs)

RESCUE MOTORS REPLACE THOUSANDS OF OEM MODELS Stock your trucks with Universal ECM motors to be prepared for your service calls RESCUE EZ16® Blower Motor RESCUE EZ13® Blower Motor S83-271 Mfg. #5862 S83-125 Mfg. #5632 Universally compatible with all 2.0, 2.3, EON motors and Nidec 16X4W Diam.: 5-5/8” HP: 1/2-1/3 Volts: 115/208-230 Replaces X13, Endura Pro and SelecTech constant torque ECM Diam.: 5-5/8” HP: 1/2-1/3 Volts: 115/208-230 S83-128 Mfg. #6633 Diam.: 5-5/8" HP: 1/2-1/3 Volts: 115/208-230 RESCUE SELECT Pro™ Blower Motor S89-095 Mfg. #5462 Diam.: 5-5/8" HP: 1/3-1/6 Volts: 208-230 RESCUE® Condenser Fan Motor S89-093 Mfg. #5460 Diam.: 5-5/8" HP: 1/2-1/6 Volts: 115 RESCUE® Direct Drive Blower Motor S81-645 Mfg. #5532ET Diam.: 5-5/8" HP: 1/2-1/4 Volts: 115/230 RESCUE EcoTech® Motor Quick install video online* *must be logged in to view

JOHNSTONESUPPLY.COM MOTORS & MOTOR ACCESSORIES Belt Drive Motors 48 Frame Split-Phase �� 24 48 Frame Split-Phase & Capacitor Start �� 25 56 Frame Split-Phase �� 25 56 Frame Split-Phase & Capacitor Start �� 25 Condenser Fan Motors 42 Frame Permanent Split Capacitor �� 26 48 Frame ECM Motors �� 26-27 48 Frame Permanent Split Capacitor ��27-36 48 Frame PSC & Three-Phase �� 38 56 Frame Permanent Split Capacitor ��37-38 56 Frame PSC & Three-Phase �� 38-39 56 Frame Three-Phase �� 40-41 Definite Purpose Motors 3-3/8" OEM Replacement Draft Inducers �� 45-47,49-58 Attic Fan Motors �� 59 Bath Vent & Range Hood Motors �� 59-61 Beverage/Ice Machine Motors �� 61 Carbonator Pump Motors �� 61 Evaporative Cooler Motors �� 62-63 Farm Duty Motors �� 63 Hot Water Circulating Pump Motors �� 63 Mobile Home & Travel Trailer Motors �� 64 OEM Special Replacement Motors �� 64-93 Oil Burner Motors �� 93-94 Refrigeration ECM Motors �� 95-99 Refrigeration Evaporator Fan Motors ��99-100 Unit Bearing Fan Motors ��100-104 Direct Drive Motors 3-3/8" Diameter Shaded Pole �� 4 3-3/8" Diameter Shaded Pole & PSC �� 2 4-7/16" and 5" Diameter Shaded Pole & PSC �� 7 4-7/16" Diameter Shaded Pole �� 6 48 Frame ECM Motors ��11 48 Frame Permanent Split Capacitor ��17-23 5" Diameter Shaded Pole & PSC �� 17 Double Shaft Motors 3-3/8" Diameter Shaded Pole & PSC ��41-42 4-7/16" Diameter Shaded Pole & PSC �� 42 48 Frame Permanent Split Capacitor ��44-45 5" Diameter Shaded Pole & PSC �� 42-44 General Purpose Motors 48 Frame Capacitor Start Dripproof ��106-107 48 Frame Split-Phase Dripproof ��104-105 48 Frame Three-Phase ��115 56 Frame C-Face �� 113-114 56 Frame Capacitor Start Dripproof ��108-110 56 Frame Capacitor Start TEFC �� 110-111 56 Frame Single-Phase ��115 56 Frame Split-Phase Dripproof ��105-106 56 Frame Three-Phase �� 115-118 T-Frame Capacitor Start �� 112-113 T-Frame Three-Phase Energy Efficient ��119 T-Frame Three-Phase Premium Efficient �119-126 Motor Accessories Blower Wheels ��149-150 Fan Blades ��137-148 Grounding Rings ��165-166 Motor Mounting Parts ��151-156 Motor Run Capacitors ��129-137 Motor Start Capacitors �� 128 Motor Starters ��156-157,159-163 Shafts & Mounting Parts ��150-151 Speed Controls & Switches �� 163 Tools �� 164-165 Variable Frequency Drives ��166-167 Motor Definitions Electric Motor Terminology �� 189 Motor Efficiency Federal Requirements �� 127 General Information �� 127 Power Transmission Bearings ��167-172 Classical V-Belts ��172,174-179 High-Efficiency Cogged V-Belts ��180-181 Sheaves ��182-188

2 ©2026 Johnstone Supply, LLC DIRECT DRIVE MOTORS 3-3/8" Diameter Shaded Pole & PSC Heatcraft Direct Replacement Motor The “3-in-1” Energy Efficient Motor • Direct replacement for Heatcraft Applications: • Direct replacement for Bohn, Chandler, Climate Control and Larkin Features: • Replaces 1/12 HP, 1/15 HP and 1/20 HP PSC and low efficiency shaded pole designs • PSC design Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. Each S58-998 9721 3-3/8" 1/12-1/20 115/208-230 1550 1 1.10 52% 5/16" 3-1/4" Rev. Ball 4.8 305.00 3.3" Diameter Refrigeration Evaporator Motor PSC • High efficiency PSC motors for refrigeration evaporator application • Four 8-32 x 3/4" stud extensions at each end • Ball bearings have all-angle thrust system • Automatic reset thermal overload protector • PSC design with capacitor included • Lyall plugs for reversing • 416 stainless steel shaft Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. Each S59-629 9721 3.3" 1/12-1/20 115/208-230 1550/1350 1 1.10/0.57 & 1.20/0.62 0.265" 3-1/4" CCWSE REV Ball 5.0 315.00 RESCUE® Refrigeration Evaporator Motors PSC • High efficiency • Uses over 40% less electricity than standard shaded pole designs • Open Air Over Applications: • Designed to meet manufacturer's requirements for fans and blowers Features: • Capacitor included • Automatic thermal protection • Ball bearings • Four 8-32 x 3/4" stud extensions at each end • Dual studs • 12" leads • Class B insulation • 40° C ambient operating temperature Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. For Use With Capacitor To Match Each A S59-317 9662 3.3" 1/20 115 1550 1 0.85 60% 5/16" 3" Rev. Ball 4.0 Bohn, Larkin Included 249.00 A S58-963 9656 3.3" 1/15 208-230 1550 1 0.60 60% 5/16" 2-1/2" Rev. Ball 4.0 Bohn, Larkin Included 239.00 B S59-318 9664 3.3" 1/12-1/20 115/230 1550 1 1.20/0.60 60% 5/16" 2-1/2" Rev. Ball 4.0 Bohn, Larkin Included 219.00 Refrigerator Evaporator Motors PSC • Uses over 40% less electricity than standard shaded pole designs • OAO and TEAO enclosures Features: • Capacitor included • Automatic thermal protection • Ball bearings • Four 8-32 x 3/4" stud extensions at each end • Dual studs • 12" leads • Class B insulation • 40° C ambient operating temperature Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. For Use With Capacitor To Match Each Open Air Over Enclosure S59-323 9624 3.3" 1/50 115 1550 1 0.43 60% 1/4" 2-1/4" Rev. Ball 4.0 — Included 175.00 S59-324 9628 3.3" 1/30 115 1550 1 0.60 60% 5/16" 2-1/4" Rev. Ball 4.0 — Included 179.00 S59-319 9632 3.3" 1/20 115 1550 1 0.85 60% 5/16" 2-19/50" Rev. Ball 4.0 — Included 199.00 S59-322 9648 3.3" 1/20 230 1550 1 0.36 60% 5/16" 2-1/4" Rev. Ball 4.0 Fedders Included 239.00 S59-325 9657 3.3" 1/10 230 1550 1 0.70 60% 5/16" 3-3/4" Rev. Ball 5.0 Heatcraft Included 305.00 Totally Enclosed Air Over Enclosure S59-326 9641 3.3" 1/50 115 1550 1 0.50 60% 1/4" 2-1/4" Rev. Ball 4.0 — Included 255.00 S59-320 9654 3.3" 1/20 115/230 1550 1 0.80/0.40 60% 5/16" 1-63/100" CWSE Ball 4.0 Krack Included 319.00 A B

JohnstoneSupply.com 3 DIRECT DRIVE MOTORS 3-3/8" Diameter Shaded Pole & PSC Multi-Horsepower Fan and Blower Motor PSC • 1/12 HP, 1/15 HP and 1/20 HP Motor • Open ventilated Features: • Sleeve bearing • Dual voltage • Thermally protected • Manufactured with low temperature oil Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Bearing Type Wt. Lbs. Capacitor To Match Each S59-241 D1127 3-3/8" 1/12-1/20 115/230 1550 1 1.10 65% 5/16" 3" Slv 4.0 Included 275.00 1500 RPM Open Ventilated Motors Shaded Pole • Open air over Applications: • Electric wall and ceiling heaters, gas and oil heaters, range hood vents, fans, blowers, etc. Features: • Open ventilated enclosures, to be located in the airstream, thermally protected • Studs: four on 2.84" centers, both ends of motor Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each A S58-219 D120 3-3/8" 1/70 115 1500 1 0.70 35% 1/4" 2-1/4" CWSE 2-1/8" Slv 2.0 199.00 A S58-220 D121 3-3/8" 1/70 115 1500 1 0.70 35% 1/4" 2-1/4" CCWSE 2-1/8" Slv 2.0 205.00 B S59-448 D609 3-3/8" 1/50 115 1500 1 0.90 35% 1/4" 2-1/4" CCWSE 2-3/16" Slv 3.0 229.00 A S58-183 D126 3-3/8" 1/40 115 1500 1 1.10 35% 5/16" 2-1/4" CWSE 2-1/2" Slv 2.1 225.00 A S58-221 D127 3-3/8" 1/40 115 1500 1 1.00 35% 5/16" 2-1/4" CCWSE 2-1/2" Slv 2.5 229.00 C S58-234 D190 3-3/8" 1/40 230 1500 1 0.60 35% 1/4" 2-1/4" CW 2-1/2" Slv 2.5 355.00 D S59-449 D515 3-3/8" 1/30 115 1500 1 1.30 35% 5/16" 2-1/4" CCWSE 2-5/8" Slv 3.2 279.00 A S58-793 D514 3-3/8" 1/30 115 1500 1 1.30 35% 5/16" 2-1/4" CWSE 2-3/4" Slv 3.2 315.00 C S58-233 D532 3-3/8" 1/30-1/12 115 1500 2 1.40 35% 5/16" 1-1/2" CW 2-3/4" Slv 3.5 429.00 A S58-222 D132 3-3/8" 1/20 115 1500 1 1.80 35% 5/16" 2-1/4" CWSE 2-5/8" Slv 3.2 205.00 A S58-223 D133 3-3/8" 1/20 115 1500 1 1.80 35% 5/16" 2-1/4" CCWSE 2-5/8" Slv 3.2 205.00 C S58-581 D189 3-3/8" 1/20 230 1500 1 0.90 35% 5/16" 2-1/4" CCW 2-5/8" Slv 3.2 219.00 A S58-777 D109 3-3/8" 1/15 115 1600 1 2.00 35% 5/16" 3" CWSE 3" Slv 3.7 285.00 3000 RPM Open Ventilated Motors Shaded Pole Applications: • For use on such diverse applications as hair dryers, fans, blowers, etc. Features: • 60 Hz • Open ventilated enclosure motor to be located in the airstream, thermally protected • Studs: Four on 2.84" centers, S58-788 has two mounting studs, 1/2" extension both ends of motor Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-193 D202 3-3/8" 1/85 115 3000 1 0.60 35% 1/4" 2-1/4" CW 2-3/8" Slv 2.1 255.00 S58-785 D203 3-3/8" 1/40 115 3000 1 1.00 35% 1/4" 2-1/4" CCW 2-3/4" Slv 3.0 305.00 S58-346 D206 3-3/8" 1/30 115 3000 1 1.20 35% 1/4" 2-1/4" CW 2-3/4" Slv 3.0 305.00 S58-787 D210 3-3/8" 1/25 115 3000 1 1.30 35% 1/4" 2-1/4" CW 3-1/4" Slv 3.5 325.00 S58-511 D216 3-3/8" 1/25 230 3000 1 0.70 35% 1/4" 2-1/4" CW 3-1/4" Slv 3.5 405.00 S58-788 D211 3-3/8" 1/15 230 3000 1 1.10 35% 1/4" 2-1/2" CCW 3-7/8" Slv 4.0 375.00 A B C D

4 ©2026 Johnstone Supply, LLC DIRECT DRIVE MOTORS 3-3/8" Diameter Shaded Pole & PSC Direct Drive Blower Motors Shaded Pole • Open air over Applications: • Office equipment, portable fans, electric heaters, kitchen/bath ventilators Features: • Thermally protected • Studs: Four on each end, 1/2" long on 2.84" centers, #8-32 thread both ends • Shaft: flatted Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-124 40030 3-3/8" 1/25 115 1550 1 1.70 35% 5/16" 2-1/2" CWSE 2-1/2" Slv 4.0 275.00 S58-125 40031 3-3/8" 1/25 115 1550 1 1.70 35% 5/16" 2-1/2" CCWSE 2-1/2" Slv 4.0 275.00 Draft Booster Motors Shaded Pole or PSC Features: • All-angle mount • 24V pilot duty safety switch • Sleeve bearing (except as noted) • 5/16" shaft adapter included • With centrifugal safety switch • Thermal overload protector • Self-cooling • Open ventilated Note: S88-384 is used in Economite, LSI/Miller and Mid-Continent gas units Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each Shaded Pole A S88-384 D454 3-3/8" 1/30 115 3000 1 1.50 35% 1/4" 1-1/2" CWSE 6-3/8" Slv 4.0 459.00 PSC B S88-383 D410 3-3/8" 1/10 115 3000 1 1.50 65% 1/4" 3-3/4" Rev. 7-1/8" Ball 5.8 1099.00 B S88-026 D412 3-3/8" 1/9 230 3000 1 0.70 65% 1/4" 3-3/4" Rev. 6-5/8" Ball 5.5 1145.00 Open Ventilated Motors Shaded Pole Applications: • Fans, blowers, office equipment, portable heaters, electric heaters, kitchen and bath ventilators Features: • Short body lengths makes them adaptable to limited space use • Flatted shaft, thermally protected, 60 Hz Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S59-468 D032A 3-3/8" 1/70 115 3000 1 0.60 35% 1/4" 2-1/2" CWSE 2-1/2" Slv 2.8 219.00 S59-540 D033 3-3/8" 1/70 115 3000 1 0.60 35% 1/4" 2-1/2" CCWSE 2-1/2" Slv 2.6 225.00 S59-474 D369 3-3/8" 1/60 115 900 3 1.30 -0.95 -0.65 35% 5/16" 2-1/2" CCWSE 3-3/8" Slv 4.0 525.00 S59-477 D0534 3-3/8" 1/25 115 1550 3 1.80 -1.30 -1.00 35% 5/16" 2-1/2" CWSE 3" Ball 3.6 315.00 S59-478 D535 3-3/8" 1/25 115 1550 3 1.80 -1.30 -1.00 35% 5/16" 2-1/2" CCWSE 3" Ball 3.6 315.00 S59-475 D0030 3-3/8" 1/25 115 1550 1 1.60 35% 5/16" 2-1/2" CWSE 2-5/8" Slv 3.6 189.00 S59-476 D031 3-3/8" 1/25 115 1550 1 1.90 35% 5/16" 2-1/2" CCWSE 2-5/8" Slv 3.6 189.00 A B

JohnstoneSupply.com 5 DIRECT DRIVE MOTORS 3-3/8" Diameter Shaded Pole Totally Enclosed Air Over Motors Shaded Pole Applications: • Replacements for range hoods Features: • 1500 RPM, single-speed • Studs: four on each end, 1/2" long on 2.84" centers • Two black leads 14" long, 18 gauge • Thermal overload protector Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each A S59-450 D541 3-3/8" 1/100 115 1500 1 0.60 35% 1/4" 2-1/4" CCWSE 2-1/8" Slv 2.0 245.00 B S58-216 D122 3-3/8" 1/80 115 1500 1 0.60 35% 1/4" 2-1/4" CWSE 2-1/8" Slv 2.1 219.00 B S58-217 D123 3-3/8" 1/80 115 1500 1 0.60 35% 1/4" 2-1/4" CCWSE 2-1/8" Slv 2.2 219.00 B S58-218 D124 3-3/8" 1/50 115 1500 1 0.75 35% 1/4" 2-1/4" CWSE 2-1/2" Slv 2.7 219.00 B S58-184 D125 3-3/8" 1/50 115 1500 1 0.75 35% 1/4" 2-1/4" CCWSE 2-1/2" Slv 2.7 219.00 C S59-451 D602 3-3/8" 1/50 115 1500 1 0.90 35% 1/4" 2-1/4" CWSE 2-3/16" Slv 3.0 225.00 C S59-452 D601 3-3/8" 1/50 115 1500 1 0.90 35% 1/4" 2-1/4" CCWSE 2-3/16" Slv 3.0 225.00 Totally Enclosed Air Over Motors Shaded Pole Applications: • Replacements on many range hood vent fans or blowers and may be used for other applications where the motor is located in the airstream Features: • Thermally protected • 60 Hz • Shaft: flatted • Studs: four each end, 3/4" long on 2.84" centers Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-287 D403 3-3/8" 1/60 115 3000 1 0.75 35% 1/4" 2-1/4" CCWSE 2-3/8" Slv 2.5 275.00 S58-288 D402 3-3/8" 1/60 115 3000 1 0.75 35% 1/4" 1-3/4" CWSE 2-3/8" Slv 2.5 275.00 Totally Enclosed Air Over Motors Shaded Pole Applications: • Bathroom ventilators, vent hoods, humidifiers, dehumidifiers, unit heaters, refrigerated display cases where motor is in humid or dusty locations Features: • Replacements for Broan, Duotherm, Markel, Miami Carey, Nutone, Tyler, Ventrola and others • Shaft: flatted • Studs: four, 3/4" long on 2.84" centers, #8-32 thread on both ends Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-019 40122 3-3/8" 1/100 115 1550 1 0.70 35% 1/4" 2-1/4" CWSE 2" Slv 3.0 255.00 S58-022 40123 3-3/8" 1/100 115 1550 1 0.70 35% 1/4" 2-1/4" CCWSE 2" Slv 3.0 209.00 S58-423 40124 3-3/8" 1/50 115 1550 1 0.80 35% 1/4" 2-1/4" CWSE 2-5/16" Slv 3.0 235.00 S58-011 40125 3-3/8" 1/50 115 1550 1 0.80 35% 1/4" 2-1/4" CCWSE 2-5/16" Slv 3.0 225.00 Totally Enclosed Self-Cooled Motors Shaded Pole Applications: • Central heating and direct drive blower units in humid or dusty areas Features: • Thermally protected • Shaft: flatted • Cooling case may be removed if necessary to use as totally enclosed motor • Studs: four, 3/4" long on 2.84" centers, #8-32 thread Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-228 D134 3-3/8" 1/25 115 1500 1 1.60 35% 5/16" 2-1/4" CWSE 4-1/4" Slv 4.1 449.00 S58-271 D227 3-3/8" 1/20 115 1500 1 1.70 35% 5/16" 2-1/4" CCWSE 4-1/4" Ball 5.0 569.00 S58-789 D226 3-3/8" 1/20 115 1500 1 1.60 35% 5/16" 2-1/4" CWSE 4-1/4" Ball 4.5 555.00 S58-790 D234 3-3/8" 1/15 115 1580 1 2.20 35% 5/16" 2-1/4" CWSE 4-3/4" Slv 5.0 475.00 A B C

6 ©2026 Johnstone Supply, LLC DIRECT DRIVE MOTORS 3-3/8" Diameter Shaded Pole Internally Fan-Cooled Motors Shaded Pole Applications: • For use on fans, blowers and small pumps where motor is isolated from air stream Features: • Continuous duty • Studs: four on 2.84" centers, #8-32 thread • Sleeve bearing, thermal overload protection • Open construction Note: S58-701 has four studs opposite shaft end; S58-786 is double shaft with 3-1/4" extension each end. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-701 D167 3-3/8" 1/70 115 1500 1 0.70 35% 1/4" 3" CWSE 2-7/8" Slv 2.5 369.00 S58-510 D608 3-3/8" 1/50 230 3000 1 0.60 35% 1/4" 1-5/16" CWSE 3-3/4" Slv 3.0 329.00 S58-224 D130 3-3/8" 1/40 115 1500 1 1.00 35% 5/16" 4-1/8" CWSE 3-1/3" Slv 2.8 305.00 S58-786 D209 3-3/8" 1/30 115 3000 1 1.10 35% 1/4" 3-1/4" CCWOSE 3-5/8" Slv 3.0 325.00 S89-088 D208 3-3/8" 1/30 115 3000 1 1.10 35% 1/4" 3" CWSE 3-5/8" Slv 3.0 315.00 11 Frame Replacement Motors Shaded Pole Applications: • Replaces GE motors in air conditioners, unit heaters, commercial condensing units, unit cooler fans, blowers and refrigeration cabinets Features: • Ball bearings, resilient rings for base mounting, and tapped mounting holes Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S58-534 81671 3-3/8" 1/15 115/230 1550 1 2.10 35% 5/16" 1-5/8" CCWSE 4-1/2" Ball 5.0 449.00 S58-535 81672 3-3/8" 1/15 115/230 1550 1 2.10 35% 5/16" 1-5/8" CWSE 4-1/2" Ball 5.0 485.00 Open Ventilated Air Over Motors for Fans and Roof Ventilators Shaded Pole Replacements for Sears, Acme and Others Applications: • Replacements for motors used on roof ventilators, may also be used on fan and blower applications where the motor is located in the air system Features: • Thermally protected, 60 Hz • Shafts: flatted • Studs: four studs on 3.89" centers, shaft end, 1/2" long all motors • S89-442 is a replacement for Leslie Locke #7108-5056 Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each A S89-441 D170 4-7/16" 1/20 115 1500 1 1.70 35% 5/16" 2-1/4" CWSE 2-3/4" Slv 4.5 579.00 A S88-238 D116 4-7/16" 1/15 115 1500 1 2.40 35% 3/8" 2-3/8" CWSE 3" Slv 5.0 465.00 A S89-442 D310 4-7/16" 1/12 115 1500 1 4.00 35% 3/8" 2" CWSE 2-3/8" Slv 4.5 545.00 A S87-975 D119 4-2/5" 1/11-1/35 115 1500 3 2.90 35% 1/2" 2-5/8" CCWSE 3-3/4" Ball 6.0 489.00 B S88-229 D174 4-2/5" 1/10 115 1500 1 3.50 35% 3/8" 2-7/8" CWSE 3-3/8" Slv 6.5 599.00 A S89-087 D374 4-2/5" 1/8-1/20 115 1500 2 4.00 35% 3/8" 2-1/2" CWSE 3-5/8" Slv 6.5 919.00 A B

JohnstoneSupply.com 7 DIRECT DRIVE MOTORS 4-7/16" and 5" Diameter Shaded Pole & PSC Totally Enclosed Unit Heater Motors Shaded Pole Applications: • Used for Modine and Reznor unit heaters Features: • Single-speed • Totally enclosed, non-ventilated • Sleeve bearing Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S88-836 D113 4-2/5" 1/12 115/230 1550 1 2.50 35% 3/8" 3" CCWSE 4-1/8" Slv 9.0 999.00 S88-837 D114 4-2/5" 1/12 115/230 1550 1 2.50 35% 3/8" 3" CWSE 4-1/8" Slv 9.0 985.00 S88-838 D115 4-2/5" 1/12 115/230 1550 1 2.50 35% 1/2" 2" CCWSE 4-1/8" Slv 9.0 985.00 Totally Enclosed Fan and Blower Motor PSC Unit Heater Applications: • Direct drive furnace blowers, shaft mounted fans, unit heaters or any continuous duty application where the motor is located in the airstream Features: • Continuous duty, air over • Auto protector • Leads: 60" long, with 1/4" straight terminals • Shaft: flatted • Capacitor and capacitor housing included • Three thru-bolts on a 4.42" diameter bolt circle • Replaces mfg. #322P611 Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Each S88-287 U6520 5" 1/8 115 1075 1 2.60 65% 1/2" 2-1/4" Rev. 3-7/8" 4-5/8" Slv 12.2 805.00 Open Ventilated Refrigeration Replacement Motors Shaded Pole Applications: • Unit cooler fans and blowers, refrigeration cabinets, unit heaters, space heaters, remote air conditioners, blower units and other air moving applications • For many popular commercial condensing units (Copeland, Tecumseh, Hussmann, Tyler, etc.) Features: • Single-speed, all-angle sleeve bearing, 42Y frame • These four motor ratings replace 21 of GE’s 21/29 frame designs • 1/2" shaft adapter included, mechanically reversible • Extended studs on 3-1/2" bolt circle for stud mounting (mounting washers and nuts included) • Extended hubs with 2-1/4" rubber rings for base mounting • Automatic reset thermal protection Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Each S88-444 RF6402 5" 1/10 115/208-230 1050 1 4.00 35% 3/8" 2-1/4" CWSE - Mech. Rev. 3-13/16" 4-9/16" Slv 11.4 475.00 S88-445 RF6403 5" 1/10 115/208-230 1050 1 4.00 35% 3/8" 2-1/4" CCWSE - Mech. Rev. 3-13/16" 4-9/16" Slv 12.0 479.00 S88-442 RF4400 5" 1/10 115/208-230 1550 1 4.00 35% 3/8" 2-1/4" CWSE - Mech. Rev. 3-13/16" 4-9/16" Slv 10.2 445.00 S88-443 RF4401 5" 1/10 115/208-230 1550 1 4.00 35% 3/8" 2-1/4" CCWSE - Mech. Rev. 3-13/16" 4-9/16" Slv 10.0 445.00 Direct Drive Ventilation Motor PSC, 42YZ Frame, Open Air Over Features: • Capacitor included and mounted • Automatic thermal protection • Continuous duty Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Capacitor To Match S58-964 4742 5" 1/6 115 1650 1 2.70 54% 1/2" 3" CWLE 3-7/8" Ball 10.0 Included

8 ©2026 Johnstone Supply, LLC DIRECT DRIVE MOTORS 5" Diameter Shaded Pole & PSC Resilient Bases For 4-5/16", 5", 5-1/2" and 5-5/8" Diameter Motors • Check “A” dimension of motor (overall body length, excluding hubs) • Select base that fits motor body length • Verify correct shaft height (“D” dimension) Note: Resilient mounting rings, mounting clips and adapter rings not included. Order # Mfg. # Base Length D A Length for 4-5/16" Diam. A Length for 5-5/8" & 5" Diam. 2E 2F Each S58-356 1206 4-3/16" 2-11/16" 3-1/2" 3-3/4" 3-7/8" 1-11/16" 135.00 S58-357 1207A 4-11/16" 2-11/16" 4" 4-1/4" 3-7/8" 1-11/16" 135.00 S58-358 1211 4-3/16" 3" 3-1/2" 3-3/4" 3-15/16" 1-11/16" 85.00 S58-359 1212 4-11/16" 3" 4" 4-1/4" 3-15/16" 1-11/16" 75.00 S58-360 2061 3-15/16" 3" 3-1/4" 3-1/2" 3-15/16" 1-11/16" 99.00 S58-361 1422 4-7/16" 3" 3-3/4" 4" 4-1/4" 2-3/4" 79.00 S58-362 1226 4-7/8" 3" 4-1/4" 4-1/2" 3-15/16" 1-11/16" 85.00 S58-363 1292 5-1/8" 3" 4-1/4" 4-3/4" 3-15/16" 1-11/16" 85.00 S58-365 1340 5-11/16" 3" 5" 5-1/4" 4-1/4" 2-3/4" 95.00 S58-369 2062 3-15/16" 3-1/2" 3-1/4" 3-1/2" 3-15/16" 1-11/16" 105.00 S58-370 1209A 4-3/16" 3-1/2" 3-1/2" 3-3/4" 3-15/16" 1-11/16" 85.00 S58-373 1347 5-3/16" 3-1/2" 4-1/2" 4-3/4" 3-15/16" 1-11/16" 85.00 S58-374 1419 5-11/16" 3-1/2" 5" 5-1/4" 4-1/4" 2-3/4" 95.00 21/29 Frame Replacement Motors PSC, 42 Frame, Open Dripproof Air Over Applications: • Four motors replace over 30 GE Motors used for air conditioners, refrigerated cabinets, window fans, etc. • Complete mounting provisions for replacing 21/29 frame motors Features: • Versatile all-angle operation • Single-speed • Mechanically reversible • Dummy end shield can be moved on the extended thru-bolts to fit existing base • Threaded holes and bolts for 21/29 frame end mounting, 2-1/4" hub rings, resilient mount • 1/2" shaft adapter furnished, flatted shaft • Automatic thermal protection • Capacitor included Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S81-178 1468P 5" 1/20 115/208-230 1550 1 2.20 36% 3/8" 3-3/10" CCWSE 3-1/2" SAB 7.0 675.00 S81-177 1469P 5" 1/15 115/208-230 1550 1 1.30 38% 3/8" 3-1/2" CWSE 3-1/2" SAB 8.4 709.00 S81-176 1470P 5" 1/10 115/208-230 1550 1 3.80 46% 3/8" 3-1/2" CWSE 3-1/2" SAB 7.0 715.00 S81-175 1471P 5" 1/10 115/208-230 1050 1 1.70 51% 3/8" 3-1/4" CWSE 4" SAB 7.0 725.00 21/29 Frame Motors PSC, 42 Frame, Open Air Over Applications: • Direct drive furnace blowers, air conditioners, fans, blowers and locations where the motor is located in the airstream Features: • Rotation: electrically reversible • Resilient rings for base mounting • 3-speed • Sleeve bearing for all-angle mounting • Capacitor not included Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each S89-021 2824 5" 1/8 115 1075 3 2.50 1/2" 4" Rev. 4-5/16" 4-15/16" Slv 8.7 G21-930 709.00 S89-026 2828 5" 1/4 208-230 1075 3 2.20 1/2" 4" Rev. 5-1/16" 5-11/16" Slv 11.9 G21-930 825.00

JohnstoneSupply.com 9 DIRECT DRIVE MOTORS 5" Diameter Shaded Pole & PSC Direct Drive Blower Motors PSC, 42 Frame, Open Air Over Applications: • Direct drive blower motor suitable for a wide variety of air moving applications such as refrigeration condensers, unit heaters, unit coolers, central air conditioning, etc. Features: • Automatic thermal protector • Sleeve bearing • Includes 2-1/2" resilient rings • Rotation is non-reversible Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each S81-180 1127P 5" 1/6 115 1050 1 6.00 54% 1/2" 4" CCWLE 4-1/16" 4-3/4" SAB 12.0 — 489.00 S88-580 8952 5" 1/5 208-230 1075 3 1.60 62% 1/2" 4" Rev. 4-5/16" 4-7/8" SAB 11.0 G21-930 689.00 Unit Heater and Furnace Blower Motors Applications: • Unit heaters, furnace blower, fans and blowers • Open ventilated PSC motors designed as OEM replacement furnace blower/unit heater motors for Payne, Day & Night, Bryant, Reznor, Intertherm, Coleman, Janitrol, etc. Features: • Thermally protected, capacitor leads with 1/4" flag terminals, reversing plug • Shaft: 2-1/2" flatted • Studs: three or four on 4.62" centers, 13/16" long, #10-32 thread, on shaft end of motor • Resilient rings: not included Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each S88-302 D150A 5" 1/4-1/6 115 1050 3 4.70 65% 1/2" 6" Rev. 4-1/8" 5-1/8" Slv 11.5 G21-930 605.00 S88-303 D151A 5" 1/4-1/6 230 1050 3 1.70 65% 1/2" 6" Rev. 4-1/8" 5-1/8" Slv 11.0 G21-930 615.00 Heating and Ventilation Motor Shaded Pole, 42 Frame, Open Air Over Applications: • Designed as a replacement on central heating and direct drive blower units • May also be used for ventilators, exhaust fans, etc. Features: • Thermally protected, sleeve bearing • Replacement for Siegler & Williams wall heaters Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Each S89-413 D143 5" 1/30-1/40 115 1050 2 1.50 35% 1/2" 1-5/8" CCWSE 2-1/4" Slv 5.0 565.00 PSC 4-Speed Single Shaft Fan Coil Motor For McQuay, Trane and Other Single Shaft Fan Coil Units Applications: • 4-speed, PSC direct drive motor most often drives an 8" wide blower wheel in fan coil units Features: • Rotation: reversible, capacitor included Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Each S88-660 D290A 5" 1/10-1/40 115 1050 4 2.20 65% 1/2" 8-1/2" Rev. 3-1/4" 4-1/4" Slv 7.5 869.00 Hundreds of FREE Product Courses Sign up today at: JohnstoneUniversity.com FREETO SIGN UP FOR ONLINE TRAINING TECHNICAL • CUSTOMER SERVICE • SAFETY & COMPLIANCE BUSINESS • NATE CEH’S

10 ©2026 Johnstone Supply, LLC DIRECT DRIVE MOTORS 5" Diameter Shaded Pole & PSC 1-, 2-, 3- and 4-Speed Fan and Blower Motors Shaded Pole or PSC, 42 Frame, Open Air Over Applications: • Direct drive furnace blowers, shaft mounted fans, unit heaters or any continuous duty application where the motor is located in the airstream Features: • Automatic reset thermal protectors • All motors have 30" leads • S88-272 has extended mounting studs on the shaft extension end of the motor Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each PSC A S88-273 BL6505A 5" 1/5-1/10 115 1075 3 3.20 65% 1/2" 5" Rev. 3-7/8" 4-5/8" Slv 9.7 G21-933 619.00 A S88-274 B6507A 5" 1/5-1/10 230 1075 3 1.30 65% 1/2" 5" Rev. 3-7/8" 4-5/8" Slv 10.8 G21-933 625.00 B S89-856 390A 5" 1/4-1/7 115 1050 3 3.70 65% 1/2" 6" Rev. 4-1/4" — Slv 12.0 G21-933 695.00 A S89-773 BL6519A 5" 1/4-1/6 115 1075 3 4.70 65% 1/2" 4-7/8" Rev. 4-1/16" — Slv 11.3 G21-930 645.00 A S89-774 B6520A 5" 1/4-1/6 230 1075 3 2.00 65% 1/2" 4-7/8" Rev. 4-1/16" — Slv 11.4 G21-930 615.00 Shaded Pole A S88-267 BL6410 5" 1/8 115 1050 1 5.20 35% 1/2" 4-7/8" CCWLE 3-3/8" 4-1/8" Slv 8.8 — 485.00 A S89-770 BL6412 5" 1/6 115 1050 1 5.50 35% 1/2" 3-5/8" CCWLE 3-7/8" 4-5/8" Slv 8.7 — 419.00 A S89-771 BL6420 5" 1/6-1/9 115 1050 2 5.60 35% 1/2" 3-5/8" CCWLE 3-7/8" 4-3/8" Slv 9.0 — 449.00 A S88-270 BL6414 5" 1/5-1/10 115 1050 3 6.50 35% 1/2" 4-7/8" CCWLE 3-7/8" 4-9/16" Slv 11.1 — 445.00 A S88-272 BL6416 5" 1/5-1/15 115 1050 4 7.10 35% 1/2" 2" CCWLE 3-7/8" 4-5/8" Slv 10.8 — 685.00 A S88-271 B6415 5" 1/5-1/10 208-230 1050 3 3.20 35% 1/2" 4-7/8" CCWLE 3-7/8" 4-5/8" Slv 11.1 — 575.00 Furnace Blower Motors PSC, Open Air Over Applications: • Furnace blowers, attic ventilators, air handlers and fan coil units Features: • Continuous duty • Thermally protected Fig. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. “R” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each PSC A S89-768 669A 5" 1/10-1/35 115 1050 4 1.70 65% 1/2" 8-1/2" Rev. 3-1/2" 4" Slv 9.0 Included 979.00 B S89-769 690 5" 1/6 208-230 1110 1 1.03 65% 1/2" 1-3/4" Rev. 4-1/4" — Slv 10.3 G21-930 535.00 277 Volt Fan Motor Features: • 4-speed PSC motor, sleeve bearing • Rotation: electrically reversible • Extended hubs both ends, weighs 11 lbs. Order # Mfg. # Diam. HP Volts RPM Speeds F/L Amps Efficiency Shaft Diam. Shaft Length Rot. “A” Dim. Bearing Type Wt. Lbs. Capacitor To Match Each S88-683 D152A 5" 1/4-1/8 277 1050 4 1.50 65% 1/2" 6" Rev. 4-1/8" Slv 11.0 G21-930 935.00 A B A B

JohnstoneSupply.com 11 DIRECT DRIVE MOTORS 48 Frame ECM Motors RESCUE EZ13® Blower Motors • Universal ECM replacement for furnaces and air handlers • Built-in 6,000 volt surge protection • Replaces X13, Endura Pro and SelecTech constant torque ECM • Truck stock • Universal replacement • Ready to install • Replaces Thousands of OEM Models • Pre-programmed with Universal Program, no programming required • Inputs: 24Vac, tap inputs • Rotation: Auto-Rotation sensing • Hertz: 60 & 50 Hz • Operation mode: constant torque • NEMA 48 frame, open air over (OAO) Enclosure, Belly-band Mounting • Up to 82% Efficiency Order # Mfg. # Diam. HP Volts RPM F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. Each S83-125 5632 5-5/8" 1/2-1/3 115/208-230 1075 6.30/4.00-3.80 & 6.40/4.00-3.80 82% 1/2" 5.0" Rev. Ball 10.0 779.00 S83-124 5642 5-5/8" 3/4 115/208-230 1075 9.30/5.80-5.40 & 9.30/5.80-5.40 82% 1/2" 5.0" Rev. Ball 12.0 839.00 S83-123 5652 5-5/8" 1 115/208-230 1075 12.40/7.80-7.20 & 12.30/7.70-7.20 82% 1/2" 5.0" Rev. Ball 14.0 885.00 RESCUE® Select Pro™ Blower Motors • Programmable ECM replacement for furnaces and air handlers • Built-in 6,000 Volt surge protection • Replaces X13, Endura Pro and SelecTech constant torque ECM • Truck stock • OEM direct replacement • Programmable and tunable in operation • Replaces thousands of OEM models • Integrated Bluetooth® Technology, no additional programming tool required • RESCUE® Select Pro™ programming app offers OEM direct programming, customized airflow in operation • Inputs: 24Vac, tap inputs • Speeds: programmable (1075/Var) • Rotation: programmable (CCW or CW) • 60 & 50 Hz • Operation mode: Constant Torque • NEMA 48 Frame, open air over (OAO) enclosure, belly-band mounting Order # Mfg. # Diam. HP Volts RPM F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. Each S83-128 6633 5-5/8" 1/2-1/3 115/208-230 1075 6.30/4.00-3.80 & 6.40/4.00-3.80 82% 1/2" 5.0" Rev. Ball 10.0 855.00 S83-127 6643 5-5/8" 3/4 115/208-230 1075 9.30/5.80-5.40 & 9.30/5.80-5.40 82% 1/2" 5.0" Rev. Ball 12.0 925.00 S83-126 6653 5-5/8" 1 115/208-230 1075 12.40/7.80-7.20 & 12.30/7.70-7.20 82% 1/2" 5.0" Rev. Ball 14.0 975.00 RESCUE EZ16® Blower Motors • Universal ECM replacement for furnaces and air handlers • Built-in 6,000 volt surge protection • Field tunable with EZI (included) • Replaces thousands of OEM models • Direct drop-in • Adjustable airflow at point of installation • Multi-HP trim function to increase flexibility • Remote mount for ease of access • Universally compatible with all 2.0, 2.3, EON motors and Nidec 16X4W • Inputs: 24VAC or PWM • Rotation: CCW or CW (24VAC) / Auto-Rotation (PWM) • Hertz: 60 & 50 Hz • Operation Mode: Constant Torque • NEMA 48 Frame, Open Air Over (OAO) enclosure, belly-band mounting • Up to 82% efficiency Order # Mfg. # Diam. HP Volts RPM F/L Amps Efficiency Shaft Diam. Shaft Length Rot. Bearing Type Wt. Lbs. Each S83-270 5863 5-5/8" 1/3 115/208-230 1075 4.50/2.90-2.70 & 4.50/2.90-2.70 82% 1/2" 5.0" Rev. Ball 9.0 1099.00 S83-271 5862 5-5/8" 1/2-1/3 115/208-230 1075 6.40/4.00-3.80 & 6.40/4.00-3.80 82% 1/2" 5.0" Rev. Ball 10.0 1245.00 S83-272 5861 5-5/8" 3/4-1/3 115/208-230 1075 9.30/5.90-5.50 & 9.40/5.90-5.50 82% 1/2" 5.0" Rev. Ball 12.0 1345.00 S83-273 5860 5-5/8" 1-1/3 115/208-230 1075 12.10/7.60-7.10 & 12.10/7.60-7.10 82% 1/2" 5.0" Rev. Ball 14.0 1345.00 HVACanswers.com Get business-boosting answers, training, and resources now. GET COMFORTABLE WITH CHANGE Explore A2L benefits and guidance at HVACanswers.com  Good for the planet, good for your business  Rebates and incentives help customers save money fast  Saves energy and costs over the long haul

www.johnstonesupply.com
